( 2944/MUM/2013 ) ELECTRIC POLE CLIMBING ROBOT



Bibliographic Data



Title : ELECTRIC POLE CLIMBING ROBOT
Application Number : 2944/MUM/2013
Filing Date : 11/09/2013
Publication Date : 27/09/2013
Applicant(s) : Maharashtra State Board of Technical Education;Y.B. Patil poly;Swati Patil;Ruksar Pathan;Kalyani Waghmare;Snehel Rane;Snehal Kalokhe
Inventor(s) : Patil, Swati;Pathan, Ruksar;Waghmare, Kalyani;Rane, Snehel;Kalokhe, Snehal
International Classifications : B25J 11/00
Abstract : Accordingly following invention provides an electric pole climbing robot. The mechanism has the characteristics of compact body, easy control, good move characteristics, and is a promising application of pole climbing robot structure. The Pole climbing robot has the capability to climb over the poles and performs the desired task smoothly. Following invention is described in detail with the help of Figure 1 of sheet 1 shows remote section block diagram of the embodiment, Figure 2 of sheet 2 shows main controller block diagram of the embodiment, Figure 3 of sheet 3 shows circuit diagram of remote section, Figure 4 of sheet 4 shows main circuit diagram of the embodiment, Figure 5 of sheet 5 shows flow chart for robot and Figure 6 of sheet 6 shows flow chart for remote.
To view more details, please login to www.mcpairs.com and search for AN:"2944/MUM/2013"
